40102-202 30.5mm Mushroom and Rope Pull Operators
40102-202 30.5mm Mushroom and Rope Pull Operators
SKU: SKU: 40102202 Download PDF
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
The 305mm Mushroom and Rope Pull Operators is a hand operated control circuit device rated for 'Heavy Duty' use, typically with electromagnetic equipment Its body is composed of die-cast zinc, and the red mushroom ergonomically shaped plunger is constructed from DuPont Delrin 100ST Acetal, providing enhanced impact resistance and uniform solid color throughout.
Features and Benefits:
•UL/NISD E357870 certification.
•Nema 12/13 and IP 65 rated.
•Durable plastic mushroom operator.
•Maintained switch type with positive opening contact.
•Lightweight at approximately 0.57 lb.
Specifications:
| Operator Color | Red |
| Operator Material | Plastic |
| Operator Size | 2.00 in. |
| Padlock Feature | No |
| Switch Type | Maintained |
| Operating Force | 9.0 lb |
| Plunger Head Operator Replacement | 43200-042 |
| Old Catalog Number | R102 |
| Operating Type | Maintained |
