40102-122 30.5mm Mushroom and Rope Pull Operators
40102-122 30.5mm Mushroom and Rope Pull Operators
SKU: SKU: 40102122 Download PDF
Couldn't load pickup availability
The 305mm Mushroom and Rope Pull Operators is a hand-operated control circuit device rated as 'Heavy Duty' and typically used with electromagnetic equipment The body of the operator is composed of die-cast zinc, ensuring durability The red mushroom-shaped plunger is ergonomically designed and molded from DuPont Delrin 100ST Acetal, providing enhanced impact resistance and a solid color throughout.
Features and Benefits:
•Constructed from die-cast zinc for durability.
•Red ergonomic mushroom plunger molded from DuPont Delrin 100ST Acetal for better impact resistance.
•Nema 12/13, IP 65 rated for protection against dust and water.
•Features Positive Break with gold-plated contacts.
•Includes sliding padlock attachment for enhanced security.
Specifications:
| Operator Color | Red |
| Operator Material | Plastic |
| Operator Size | 2.00 in. |
| Padlock Feature | Yes |
| Switch Type | Maintained |
| Contact Block(s) Included | (2) 50703 (2) NO/NC |
| Operating Force | 8.0 lb |
| Old Catalog Number | R102 |
| Operating Type | Maintained |
