40102-104 30.5mm Mushroom and Rope Pull Operators
40102-104 30.5mm Mushroom and Rope Pull Operators
SKU: SKU: 40102104 Download PDF
Qty:
Unit price
per
Sold out
Shipping calculated at checkout.
IN STOCK Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
Couldn't load pickup availability
Product Information
This switch is a hand-operated control circuit device rated 'Heavy Duty' and typically used with electromagnetic equipment The body is constructed from die-cast zinc The yellow mushroom ergonomic-shaped plunger is made from DuPont Delrin 100ST Acetal for enhanced impact resistance and is solid color throughout.
Features and Benefits:
•Nema 12/13, IP 65 rated.
•Positive Break with Gold Plated Contacts.
•Sliding Padlock Attachment.
•Maintained switch type.
•Positive Opening Contact.
Specifications:
| Operator Color | Yellow |
| Operator Material | Plastic |
| Operator Size | 2.00 in. Mushroom |
| Padlock Feature | Yes |
| Operating Force | 8.0 lb |
| Contact Block(s) Included | 50703-NO/NC |
| Plunger Head Operator Replacement | 43200-044 |
| Old Catalog Number | R102 |
| Operating Type | Maintained |
