38700 - Digital Torque Display with USB, Aluminium Housing, High-Contrast TFT

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CAPTURE Hub, a digital torque display unit tailored for use with torque sensors Crafted with a lightweight yet durable aluminum casing, this device offers exceptional flexibility It seamlessly integrates with CAPTURE Manager PC software (Order Code 038710) and allows for additional sensors to be connected directly through its external port Users can mount the unit either horizontally or vertically, adapting easily to their existing setups.

This versatile hub supports multiple measurement units, including Nm, cNm, lbf·ft, lbf·in, and ozf·in, and comes with a Calibration Certificate, ensuring traceability to international standards with an accuracy of +/-1% of the reading UKAS certification is available upon request for an additional fee The design is perfect for both stationary laboratory applications and mobile data collection, featuring an onboard memory and a rechargeable lithium-ion battery that enables independent operation from mains power.

Data transmission to a PC is facilitated through a USB connection, while a clear, high-contrast TFT display enhances visibility The CAPTURE Hub is compatible with Capture CS and XR sensors for quick sensor detection, as well as standard torque sensors with a rating of 2mV/V Included in the package are complimentary evaluation PC software, a USB cable, a power supply unit with a Euro plug, user instructions, and a sturdy plastic case with an inlay for secure storage.

Features and Benefits:

•Light yet robust due to aluminium housing.

•Flexibility to integrate with CAPTURE Manager PC software.

•Mountable horizontally or vertically.

•Switchable units Nm, cNm, lbf·ft, lbf·in, ozf·in.

•Calibration Certificate traceable to International Standards with +/-1% accuracy.

•Versatile for static and mobile use with on-board memory and rechargeable battery.

•High-contrast TFT display.

•Compatible with standard torque sensors and Capture CS/XR sensors.

•Powerful lithium-ion battery for mains-independent operations.

•Includes free evaluation PC software.
