2575200000 - 5.08mm 4-Pole PCB Connector with Clamping Yoke, 180° Angle (Pack of 90)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the BLZP 508HC/04/180 SN BK BX PRT, a high-performance female plug PCB connector with a 508 mm pitch and four poles configured at a 180° angle This connector utilizes a clamping yoke method for secure and reliable connections, accommodating wire sizes up to 4 mm² Packaged in a convenient box, it meets various regulatory standards, including RoHS compliance With an operating voltage rating of 400 V and a current capacity of 23 A according to IEC, it also supports 300 V and 20 A under UL standards, making it a versatile choice for your electronic projects.

Features and Benefits:

•Clamping yoke connection for reliable performance.

•Safe from finger touch as per DIN VDE standards.

•Can be coded for secure connections.

•Lightweight at 6.266 g.

•Compliant with environmental standards.

Specifications:
