1219GNH 12.1" IP67 Rugged Sunlight Readable Optical Bonded Capacitive Touchscreen LCD Display Monitor

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

The Xenarc 1219 series of 121” touchscreen displays is perhaps the most versatile and all-encompassing product in Xenarc Technologies’ line up of products This 16:9 1000 NIT High Bright Touch screen is IP67 and IK08 rated and includes an optically bonded capacitive touchscreen, making it ideal for any harsh industrial environment The 121 inch touch panel is optically bonded to the LCD panel, eliminating the air gap between the two, increasing clarity, contrast, and durability.

Further, because the 121" touchscreen display unit is water tight and air tight, ambient humidity will not affect the clarity or viewability because of the advanced optical bonding The 1219GNH 12 inch touchscreen monitor outperforms all automotive grade panels with a wider operating temperature range of -30C ~ 85C (-22F ~ 185F) and uses an IPS panel (In-Plane-Switching), which provides a wider viewing angle, consistent and accurate colors from all viewing angles, clearer images, and stable response times.

A high contrast ratio of 1000:1 provides crisper images and vivid colors, even in direct sunlight The ruggedized full IP67 enclosure incorporates Anodized Aluminum Front Frame and SUS304 Stainless Steel Back Casing, ready for harsh environments The versatility of the 1219 series extends beyond its usability in many different environments The 1219GNH can video interface through our proprietary 26 pin cable (HDMI, VGA, AV Inputs) as well as HDMI direct into the monitor.

The 121" touchscreen display monitor comes with an HDMI output that allows you to chain up a few 1219 series 121" touchscreen monitors or output to other HDMI monitors With the included waterproof cables, the 1219GNH is IP67 on all sides and angles The casing of the 1219GNH is designed to be used as a stand-alone monitor as well as a panel mount monitor (with optional panel mount bracket PMB-1219).

VESA standard mounting holes on the back further provide users with numerous mounting options The IK08 rating makes the 1219GNH vandal resistant and shock resistant The 1219GNH was designed for those looking for a true rugged, bright, compact display, usable in just about any environment or application.

Features and Benefits:

•IP67 / NEMA6P Rated Water and Dust Resistance (Whole Unit).

•Super Wide Operating Temperature range of -22°F ~ 185°F (-30°C ~ 85°C).

•1,000NIT Sunlight Readable with Long Life LED Backlight.

•Wide Viewing Angle IPS (In-Plane Switching) LCD Panel.

•Automatic Backlight Adjustment through Built-in Ambient Light Sensor.

•Projected Capacitive Multi-Touch Touchscreen (USB).

•Optical Bonding, Anti-Reflective and Anti-Fingerprint Coating.

•Plug-N-Play with Windows 7 and up and Android devices (Downloadable drivers for other OS).

•Multi-Monitor Touchscreen Support.

•HDMI Input x 2 (HDCP), VGA Input (15 pin D-SUB) x 1 & Video Input x 2.

•HDMI Output x 1, Analog Audio Output x 1.

•Audio Input x 4 / Built-In Waterproof Speaker.

•1280x800 Native Resolution, 16x9 Aspect Ratio.

•Chip Monolithic Ceramic Capacitors for Improved Durability.

•High Performance Image and Video Signal Processor.

•AISS - Advanced Image-Scaling and Shaping.

•Last Input and Power Setting Memory.

•IR Remote Control.

•Auto Power-On upon signal detection.

•Vertical Image Flip.

•Function to Disable Front Button(s) and On Screen Text.

•AV2 Auto Switching for Backup Camera.

•VESA 75mm Mounting Holes.

•Panel Mountable with Optional hardware (PMB-1219).

•26-Pin Heavy-Duty Connector with Connector Locking.

•Ruggedized enclosure with Anodized Aluminum Front Frame and SUS304 Stainless Steel Back Casing.

•Supports 9V DC ~ 36V DC.

•"E" Mark Certified for Automotive use.

•FCC, CE, E13 Certification.

•IK08 Impact Resistant.

•ROHS, REACH, ECE R118-03 Compliant.

•36 Month/3 Year Warranty.

•30 Day No dead Pixel Guarantee.

•Transportation - Marine, Air, Heavy Vehicles, Mining, Weigh Stations, Fleet Management, Telematics, In-Car Computing, Public Transit, Cargo.

•System Integration - Machinery Controls, Factory Automation, Environmental Monitoring, Home Automation, Military, Smart Home.

•Point of Sale - Hospitality, Digital Signage, Self-Service Kiosks, Outdoor Kiosks and Signage, Casino.

•Data Monitoring - Cloud, IoT, Medical, Logistics, Inventory Management, Oil & Gas/Utilities, Law Enforcement, Broadcasting, Veterinary, First Person View.

•Broadcast & Production - Broadcast Stations, Mobile Production Vehicles, Field Rugged Deployment for your mobile workforce, Studio Video Production.

Specifications:
