11146 - SIP VoIP Paging Server with 100 Zones & Bell Scheduler

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience efficient communication with the CyberData 011146 SIP Paging Server featuring a Bell Scheduler This robust server allows users to manage up to 100 paging zones via a single SIP extension, making it ideal for VoIP phone systems Its integrated calendar-based bell scheduler can easily be accessed through a secure web interface, enabling scheduled bell alerts and the distribution of prerecorded messages across various multicast zones, as well as traditional analog paging systems.

Additionally, the device can be configured with a secondary SIP extension that acts as a night ringer, capable of playing a user-uploaded audio file The V3 Paging Server offers seamless connectivity to legacy analog paging amplifiers using a 'Page Port' type input, supporting either a balanced 600 Ohm 10Vpp signal or a 10k Ohm Hi-Z 2vpp signal It also includes connections for a dry contact relay (for page start output) and a fault sense input, enhancing its functionality.

Setting up the CyberData 011146 is straightforward, thanks to its user-friendly web-based interface that provides a graphical layout for configuring IP paging, including distinct multicast address and port number settings for each of the 100 zones The V3 Paging Server connects easily with a single CAT 5 or 6 network cable to a standard PoE 8023af compliant switch For those who purchased the SIP Paging Server with Bell Scheduler within the last two years, if your unit’s serial number begins with 1462, you are eligible for a complimentary upgrade to access the latest features.

Visit the CyberData website and select the Downloads tab to obtain your firmware upgrade.

Features and Benefits:

•Calendar-based Scheduler.

•Multi-user Login Capabilities.

•Call-in Recording for Stored Messages.

•SIP RFC 3261 compatible.

•Multicast output.

•Two SIP endpoints (one for Night Ringer).

•DTMF control of zone selection.

•Delayed Page Support.

•Line-In connection for music on hold multicasting.

•Line-out connection to support analog Amps.

•User uploadable audio files.

•Web-based configuration and firmware upload.

•Ethernet I/F 10/100 Mbps.

•PoE 802.3af OR 48vdc.

•19in rack mount option.
