0667420000 - 10A Fuse Terminal for TS 35 Rail, Red Cap (Pack of 20)

0667420000 - 10A Fuse Terminal for TS 35 Rail, Red Cap (Pack of 20)

SKU: SKU: 0667420000   Download PDF

Select a Variant:
  • 0667420000 - 10A Fuse Terminal for TS 35 Rail, Red Cap (Pack of 20)
Qty:
Regular price Now $316.99   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $316.99 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SAKS 3/35 (RED CAP) fuse terminal, engineered for reliable performance with a screw connection This terminal is ideal for medium yellow cables, supporting a rated cross-section of 10 mm² and a maximum current of 10 A, functioning efficiently at voltages up to 500 V With two connection points and designed for mounting on a TS 35 rail, it meets RoHS standards and operates seamlessly across various environmental conditions without the need for an end cover plate.

Make this dependable component a part of your electrical setup!.

Features and Benefits:

    •RoHS compliant.

    •Screw connection for robust and secure fitting.

    •Includes two connections for flexible wiring options.

    •Designed for direct mounting.

    •Rated for a maximum operating temperature of 130 °C.

Specifications:

 Depth 53.5 mm
 Height 54 mm
 Width 13 mm
 Rated voltage 500 V
 Rated current 10 A
 Clamping range (max) 16 mm²
 Clamping range (min) 1.5 mm²
 Connection direction on side
 Wire connection cross section AWG, max AWG 10
 Wire connection cross section AWG, min AWG 22
 Storage temperature -25 °C...55 °C
 Ambient temperature -5 °C…40 °C
 UL 94 flammability rating V-0
 Number of connections 2
 Mounting rail TS 35
 Volume resistance 0.56 mΩ
 Power loss 1.82 W
