04945-500 Rope Operated Sequence Switches

04945-500 Rope Operated Sequence Switches

SKU: 04945500   Download PDF

Qty:
Now $699.11   Web pricing policy
BEFORE   Now $699.11 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information
Resources

Description:

The Rope Operated Sequence Switch features a switch design that includes 1 Normally Open (NO) and 1 Normally Closed (NC) 'Slow-Make' contact It is suitable for use in standard start-stop applications and operates by changing the state of the contacts when the switch actuating arm is pulled by a cable The NO contact closes while the NC contact opens This switch does not latch and is intended solely for non-emergency applications.

When the cable force is removed, the state of the switch reverts.

Features and Benefits:

    •Includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact.

    •Designed for non-emergency applications.

    •Does not latch in any position.

Specifications:

 Trip Force 10 lb
 Operating Force Between 10 ft. Supports 1.2 lb
 Reset Type Manual
 Contact Arrangement NO + NC
 Old Catalog Number 2135
