04945-000 Rope Operated Sequence Switches

04945-000 Rope Operated Sequence Switches

SKU: 04945000   Download PDF

Qty:
Now $699.11   Web pricing policy
BEFORE   Now $699.11 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information
Resources

Description:

The Rope Operated Sequence Switch features a 'slack cable' style design with 1 Normally Open (NO) and 1 Normally Closed (NC) Slow-Make contact suitable for standard start-stop operations This switch does not latch in any position and is designed for non-emergency applications only When the actuating arm is pulled via a cable, the switch contacts will toggle; the NO contact will close while the NC contact will open.

Upon removal of force from the actuator arm, the switch returns to its original state.

Features and Benefits:

    •1 NO and 1 NC contacts for reliable operation.

    •Designed for normal start-stop applications.

    •Non-latching design for safety.

    •Manual reset type for straightforward operation.

Specifications:

 Trip Force: 10 lb
 Operating Force Between 10 ft. Supports: 1.2 lb
 Reset Type: Manual
 Contact Arrangement: NO + NC
 Old Catalog Number: 2135
