04801-012 2.25 inch Push Button with Key Lock

04801-012 2.25 inch Push Button with Key Lock

SKU: 04801012   Download PDF

Qty:
Now $769.65   Web pricing policy
BEFORE   Now $769.65 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information
Resources

Description:

The 225 inch Push Button with Key Lock is a hand-operated, key lockable control circuit device, rated 'Heavy Duty' and designed for use with electromagnetic equipment It features a black cover, painted with a dry powder paint, and a chrome plated plunger head made from die-cast zinc Gold plated contacts are employed to eliminate high resistance tarnishing, and the device is rated Nema 12/13, IP 65 Each captive terminal accepts (2) #14 AWG stranded wires, ensuring versatility and reliability.

Features and Benefits:

    •Hand-operated, key lockable control circuit device.

    •Rated 'Heavy Duty' for use with electromagnetic equipment.

    •Die-cast zinc construction for durability.

    •Gold plated contacts to eliminate high resistance tarnishing.

    •Nema 12/13 and IP 65 rated.

Specifications:

 Cover Color Black
 Plunger Color Chrome
 Operating Force 8.4 lb
 Key/Plunger Operation Key Removable Locked/Unlocked
 Contact Arrangement #54 NO + NC
 Contact Type Slow Make / Slow Break
 Approx. Shipping Weight 1.90 lb
