Belden 3125A 22 AWG 1 Pair 7x30 Stranding 16 AWG 1 Pair 26x30 Stranding 300V DeviceBus Cable

Description:-

DeviceBus for Square D/Seriplex, 2 Pair 16+22 AWG (26x30+7x30) Tinned Copper, PVC+PO Insulation, Overall Beldfoil (Data Pair Only) Shield, PVC Outer Jacket, CM

Insulation:-

Element: 16 AWG
• Material: PE - Polyethylene (Foam)
• Nominal Wall Thickness: 0.025 in

Element: 22 AWG
• Material: PE - Polyethylene (Foam)
• Nominal Wall Thickness: 0.0405 in

Outer Shield:-

• Layer: 1
• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Material Trade Name: Beldfoil
• Coverage: 100%
• Drainwire: 22 AWG 7x30 Stranding TC - Tinned Copper

Outer Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.368 in
• Nominal Wall Thickness: 0.039 in
• Separator Material: PO - Polyolefin (Foam) Tape

Standards:-

• UL Voltage Rating: 300 V RMS
• Nominal Characteristic Impedance: 120 Ohm
• Operating Temperature Range: -20°C to +75°C

Applications:-

• harsh environment, IIoT, factory or process automation, video, audio, data communication, etc

Specifications:-

• Size (AWG): 22
• No. of Pair: 1
• Stranding: 7x30
• Conductor Material: TC - Tinned Copper

• Size (AWG): 16
• No. of Pair: 1
• Stranding: 26x30
• Conductor Material: TC - Tinned Copper
• Part Number: 3125A
