Belden 1811A 14 AWG 8 Conductor 104x34 Stranding Bare Copper 300V Speaker Cable

Description:

Speaker Cable, 8 Conductor 14 AWG stranded (104x34) bare copper conductors with PVC insulation, cabled with fillers, paper wrap, flexible PVC jacket.

Insulation:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.025 in (0.64 mm)

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.04 in (1.0 mm)
• Nom. Diameter: 0.515 in (13.1 mm)
• Separator: Paper Tape

Standards:

• Voltage Rating: 300 V
• Operating Temperature: -20°C To +60°C

Applications:

• Bi-amp and Tri-amp Spkr Conn

Specifications:

• Size (AWG): 14
• No. of Conductor: 8
• Stranding: 104x34
• Conductor Material: BC - Bare Copper
• Part Number: 1811A
