1023200000 - 2.5mm² Dark Beige Terminal Block with Four Connections (Pack of 100)

1023200000 - 2.5mm² Dark Beige Terminal Block with Four Connections (Pack of 100)

SKU: SKU: 1023200000   Download PDF

Select a Variant:
  • 1023200000 - 2.5mm² Dark Beige Terminal Block with Four Connections (Pack of 100)
Qty:
Regular price Now $352.22   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $352.22 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a robust component terminal block in an understated dark beige hue, ideal for a variety of electrical applications This terminal block accommodates wire sizes up to 25 mm² and is rated for a voltage of 400 V With four distinct connections, it features a dual-level design and easily mounts onto a TS 35 rail, ensuring a streamlined setup for your projects.

Features and Benefits:

    •Designed for screwable cross-connection.

    •Four connections and two levels.

    •Compliant with RoHS standards.

    •Snap-on mounting type.

    •No internal cross-connection between levels.

Specifications:

 Depth 62.5 mm
 Height 69.5 mm
 Width 5.1 mm
 Net weight 11.9 g
 Continuous operating temp., min. -50 °C
 Continuous operating temp., max. 120 °C
 Rated voltage 400 V
 Rated current 10 A
 Clampable conductors (rated connection) 2 clampable conductors (H05V/H07V) with equal cross-section (rated connection)
 Wire connection cross-section, finely stranded, max. 4 mm²
 Standards IEC 60947-7-1
 Clamping range, max. 4 mm²
 Clamping range, min. 0.05 mm²
