1015800000 - Dark Beige Test-Disconnect Terminal, 10A, 1.5mm² Connection (Pack of 25)

1015800000 - Dark Beige Test-Disconnect Terminal, 10A, 1.5mm² Connection (Pack of 25)

SKU: SKU: 1015800000   Download PDF

Select a Variant:
  • 1015800000 - Dark Beige Test-Disconnect Terminal, 10A, 1.5mm² Connection (Pack of 25)
Qty:
Regular price Now $310.37   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $310.37 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the WDT 15/1 DB/GE test-disconnect terminal, crafted for reliable screw connections and presented in a sophisticated dark beige hue It accommodates wire sizes of up to 15 mm² and is rated for a maximum current of 10 A and voltage of 250 V This versatile terminal supports dual connections in a single level configuration, ensuring efficient performance Compliant with RoHS standards, it bears the E60693 certification number, guaranteeing its adherence to safety regulations.

Features and Benefits:

    •Screw connection type.

    •Made of Wemid material.

    •UL 94 flammability rating of V-0.

    •Operation in temperatures from -50 °C to 120 °C.

    •Closed open sides design for safety.

    •Compact size for efficient installation.

Specifications:

 Depth 66 mm
 Height 112 mm
 Width 6.4 mm
 Storage temperature -25 °C...55 °C
 Ambient temperature -5 °C…40 °C
 Rated voltage 250 V
 Nominal current 10 A
 Rated cross-section 1.5 mm²
 Clamping range, max 2.5 mm²
 Clamping range, min 0.13 mm²
 Tightening torque, max 0.6 Nm
 Tightening torque, min 0.4 Nm
