Belden 9207 20 AWG 1 Pair 7x28 Stranding 100 Ohm Twinax Cable

Belden 9207 20 AWG 1 Pair 7x28 Stranding 100 Ohm Twinax Cable

SKU: NES9207   Download PDF

Select a gauge:
  • Belden 9207 20 AWG 1 Pair 7x28 Stranding 100 Ohm Twinax Cable
Length: FT
Enter footage in the box - Cut to one length. Min 1 ft - Max 10000 ft.
Now $4.06 /FT   Web pricing policy
BEFORE   Now $4.06 /FT Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Belden 9207 20 AWG 1 Pair 7x28 Stranding 100 Ohm Twinax Cable

Description:

Twinax 100Ω, 1 Pair, 20 AWG (7x28) one tinned copper, one bare copper conductor, polyethylene insulation, polyethylene inner jacket, Duofoil (100% coverage) + a tinned copper braid shield (85% coverage), PVC outer jacket, CMG.

Insulation:

• Material: PE - Polyethylene (Foam)
• Nom. Insulation Diameter: 0.083 in (2.1 mm) and 0.236 in (5.99 mm)

Outer Shield:

• Layer 1: Type Tape, Tri-Laminate (Alum+Poly+Alum) Material, Material Trade Name Duofoil, Coverage [%] 100%

• Layer 2: Type Braid, Tinned Copper (TC) Material, Coverage [%] 85%

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.330 in (8.38 mm)
• Overall Cable Diameter (Nominal): 0.330 in (8.38 mm)

Applications:

• Computer, Instrumentation

Specifications:

• Size (AWG): 20
• No. of Pair: 1
• Stranding: 7x28
• Nom. Diameter: 0.036 in
• Impedance: 100 Ohm
• Conductor Material: TC - Tinned Copper & BC - Bare Copper
• Part Number: 9207
