Belden 88761 22 AWG 2 Conductor 7x30 Stranding Tinned Copper Electronic Cable

Description:

High Temperature Electronic, 2 Conductor 22 AWG (7x30) Tinned Copper, FEP Insulation, Overall Beldfoil Shield, FEP Outer Jacket, CMP.

Insulation:

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.007 in (0.18 mm)
• Nom. Insulation Diameter: 0.042 in (1.1 mm)

Outer Shield:

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 22 AWG (7x30) TC

Outer Jacket:

• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Thickness: 0.014 in (0.36 mm)
• Nom. Diameter: 0.116 in (2.95 mm)
• Overall Cable Diameter (Nominal): 0.116 in (2.95 mm)

Standards:

• Voltage Rating: 300 V RMS (UL Voltage Rating).
• Temperature Range: Operating range from -70°C to +200°C, with a UL temperature rating of 150°C.

Applications:

• extreme high/low temperature environments; chemical resistant; outdoor and burial applications; low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control
(24v, …); line level audio; voice communications; panel wiring
