Tattu 2305 2450KV 12N14P Brushless Quadcopter Motors
Tattu 2305 2450KV 12N14P Brushless Quadcopter Motors
SKU: SKU: TA-MOTOR-2305-2450KV
Couldn't load pickup availability
| Brand: | Tattu |
| Cell: | 2~4S |
| Configuration: | 12N14P |
| Continuous Current (A): | 20 |
| Continuous Power (W): | 280 |
| Is Featured Product: | No |
| KV: | 2450 |
| Max Burst Current (A): | ＜10S 35A |
| Max Continuous Current (A): | 60S 28A |
| Max Continuous Power (W): | 60S 360W |
| Motor Dimensions: | 28.9mm X 17.5 |
| Motor Wire Length: | 95mm |
| Over 300wh: | No |
| over_power: | No |
| Preorder Config: | No |
| Shaft Diameter: | 4mm |
| Sorting: | Motor |
| UPC: | 889551003001 |
| Stator Length: | 5mm |
| Stator Diameter: | 23mm |
| Stator Length: | 5mm |
| Weight (g): | 29.5 |
| Part N: | TA-MOTOR-2305-2450KV |
Tattu 2305 2450KV 12N14P Brushless Quadcopter Motors
Applications:
Tattu 2305 2450KV motors are mainly suitable for 180-250mm quadcopter frames, the compatible propeller sizes are 5040 / 5045 two-blade or three-blade propellers, they are made for FPV Racing drones.
Also Known As:
Tattu Battery, Lipo Battery, TattuFPV Battery, TA-MOTOR-2305-2450KV-4PCS Battery.
Description:
RMP: 2450KV Configuration: 12N14P Max Efficiency: 85% Voltage : 2~4S Insulation Class: A Insulation resistance: 100V 10MΩ Internal Resistance: 51mΩ Continuous Current (A): 20A Max Continuous Current (A): 60S 28A Max Burst Current ＜10S 35A Continuous Power (W): 280W Max Continuous Power (W): 60S 360W Stator Diameter: 23mm Stator Length: 5mm Motor Diameter: 28.9mm X 17.5 Shaft Diameter: 4mm Motor Wire Length: 95mm Weight: 29.5g (it's for 1pcs, not 1 set
