50726-000 Contact Blocks
50726-000 Contact Blocks
SKU: SKU: 50726000 Download PDF
Qty:
Unit price
per
Sold out
Shipping calculated at checkout.
IN STOCK Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
Couldn't load pickup availability
Product Information
Description:
This contact block is designed for use on ALL REES push button operators and selector switches Each captive terminal on the contact block will accept (2) #14 AWG stranded wires Gold plated contacts eliminate high resistance tarnishing.
Features and Benefits:
•Designed for use on ALL REES push button operators and selector switches.
•Each captive terminal accepts (2) #14 AWG stranded wires.
•Gold plated contacts prevent high resistance tarnishing.
Specifications:
| Electrical Ratings: | HEAVY DUTY – A600 / N150 |
| Listed under UL: | 508 – File # E 58589 |
| Certified under CSA: | C22.2 – File # LR 3648 |
| CE Compliant: | IEC/EN 60947-5-1 |
| Environmental Temperature Range: | +32 o F to + |
| Approx. Shipping Weight: | 0.10 lb |
