40001-002 30.5mm Push Buttons

Description:

The 305mm Push Buttons are hand-operated control circuit devices rated as 'Heavy Duty', primarily designed for use with electromagnetic equipment The switch features a die-cast zinc body for durability The plungers are also crafted from die-cast zinc, enhanced with a red plastic (poly-carbonate) insert, ensuring both functionality and visual clarity during operation Additionally, each operator can accommodate up to three tiers of two contact blocks, allowing for a total of six separate circuits, making it versatile for various applications.

Features and Benefits:

•Heavy Duty design suitable for electromagnetic equipment.

•Body and plungers made from durable die-cast zinc.

•Red plastic insert enhances visibility.

•Can accept up to three tiers of two contact blocks for multiple circuits.

•Rated NEMA 12/13 and IP 65 for protection against dust and water.

Specifications:
