04962-212 Cable/Rope Operated Switches with Broken Cable Detection

04962-212 Cable/Rope Operated Switches with Broken Cable Detection

SKU: SKU: 04962212   Download PDF

Qty:
Regular price Now $961.86   Web pricing policy
Regular price BEFORE   Sale price Now $961.86 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information
Resources

Description:

The 04962-212 Cable/Rope Operated Switch is designed with broken cable detection and features a taut cable style with 2 Normally Open (NO) and 2 Normally Closed (NC) contacts It offers Positive Break and Positive Transfer features, making it particularly competent for Emergency Stop applications and ordinary circuit control The switch is pre-wired with a red 24-volt LED indicator light for visual feedback.

The housing is constructed from high-quality die-cast aluminum and finished with powder coating in yellow Set-up position can be easily achieved without needing to remove the cover.

Features and Benefits:

    •Taut cable style switch with 2 NO and 2 NC contacts.

    •Positive Break and Positive Transfer features.

    •Suitable for Emergency Stop applications and circuit control.

    •Pre-wired with a red 24-volt LED indicator light.

    •Durable die-cast aluminum housing with yellow powder coating.

    •Easily adjustable set-up position without cover removal.

    •Emergency Stop applications.

    •Ordinary circuit control.

Specifications:

 Operating Force Between 10 ft: 15.0 lb
 Contact Arrangement: 2 NO + 2 NC, Manual Reset
 Direction of Pull: left
 Connector: No Connector
 Indicator Light: Yes
