04945-100 Rope Operated Sequence Switches

04945-100 Rope Operated Sequence Switches

SKU: 04945100   Download PDF

Qty:
Now $699.11   Web pricing policy
BEFORE   Now $699.11 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information
Resources

Description:

The Rope Operated Sequence Switch features 2 Normally Open (NO), Slow-Make contacts designed for normal start-stop operations This switch does not latch in any position and is intended solely for non-emergency applications The mechanism involves pulling the switch actuating arm with a cable, which closes the NO contacts Once the force on the cable is removed, spring pressure returns the arm to its normal position.

Features and Benefits:

    •2 Normally Open (NO) contacts.

    •Non-latching for safety.

    •Manual reset type.

    •Designed for normal start-stop applications.

Specifications:

 Trip Force 10 lb
 Operating Force Between 10 ft. Supports 1.2 lb
 Reset Type Manual
 Contact Arrangement 2 NO
 Old Catalog Number 2135
