Belden 9966 22 AWG 2 Conductor 19x34 Stranding Tinned Copper 600V Electronic Cable

Description:

Electronic, 2 Conductor 22 AWG (19x34) Tinned Copper, PVC-NYL Insulation, Overall Tinned Copper Braid (90%) Shield, PVC Outer Jacket.

Insulation:

• Material: PVC/Nylon - Polyvinyl Chloride + Nylon
• Nom. Thickness: 0.0125 in (0.318 mm)
• Insulation Nom. Insulation Diameter: 0.056 in (1.4 mm)
• Nylon Nom. Insulation Diameter: 0.003 in (0.076 mm)

Outer Shield:

• Shield Type: Braid
• Material: Tinned Copper (TC)
• Coverage: 92%
• An overall tinned copper braid shield with 90% coverage, providing protection against electromagnetic interference (EMI) and radio frequency interference (RFI).

Outer Jacket:

• Material: PVC - Polyvinyl Chloride
• Nom. Thickness: 0.02 in (0.51 mm)
• Nom. Diameter: 0.174 in (4.42 mm)

Standards:

• Voltage Rating: Rated for 600V.
• Military Compliance: MIL-W-16878E/17 (insulated conductor)
• Operating Temperature: Suitable for use in temperatures ranging from -20°C to +105°C.

Applications:

• MIL-W-16878 (Type B) Spec; up to 600V analog signals ; up to 600V voltage control
