Belden 1099A 16 AWG 12 Triads 600V Tray Cable
Belden 1099A 16 AWG 12 Triads 600V Tray Cable
SKU: SKU:
Select a gauge:
- Belden 1099A 16 AWG 12 Triads 600V Tray Cable
- Belden 1099A 16 AWG 12 Triads 600V Tray Cable
Length:
FT
Enter footage in the box - Cut to one length. Min 1 ft - Max 10000 ft.
Unit price
per
Sold out
Shipping calculated at checkout.
IN STOCK Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
Couldn't load pickup availability
Product Information
Product Details
Overall Cabling Lay Length and Direction:
• Length (in.): 12.000
Mechanical Charactertistics (Overall):
• Bulk Cable Weight: 686.800 lbs/1000 ft.
• Max. Recommended Pulling Tension: 1590 lbs.
• Min. Bend Radius/Minor Axis: 10.500 in.
Electrical Characteristics (Overall):
• Nominal Outer Shield DC Resistance @ 20°C (Ohm/1000 ft): 2.74
| technical specification: | |
| awg | 16 |
| # triads | 12 |
| stranding | 7x24 |
| no. of conductors | 36 |
| conductor material | bare copper |
| outer shield - type | tape |
| outer shield - material | aluminum foil-polyester tape |
| overall cable- nominal dia. (mm) | 26.594 |
| belden cable part number | 1099A |
